[ Specification ]
- Type : Triple Infrared, Outdoor, Non explosion-proof, Particulate
- Nominal sensing range : 30 m
- Sensing angle : 90°, Cone type
- Explosion-proof class : T6,IP67,IIC(Korea Gas Safety
- Corporation)
- Operating temp. :-40 ~ +75°C
- Keeping temp. : -50 ~ +90°C
- Humidity : 0~95 %
- Explosion proof :
- -Ex d IIC T5/T6 IP67 (KGS)
- –Ex tD A21 IP67 T100°C (KGS)
- water tight : IP67 (KGS)
- Output signal
- – RELAY
- – Fire : 5 A (250 VAC, 30 VDC), A connect point
- – O.C (Open Collector)
- Fire : MAX DC 32 V, 10 mA
- Error : MAX DC 32 V, 10 mA
- – 4~20mA
- – RS485
- Function
- – Diagnostic sensor fault enable – Self test
- – Remote self diagnostic ON / OFF control ( BIT )
|
[ Structure ]
- Material : Aluminum 6061
- Surface : Anodizing Process
- Color : Red
- Weight : About 0.53 ㎏
- External : 64 mm × 64 mm × 75mm, Hexahedral, Connector 1/2 inch PF
[ Electrical ]
- Power Cunsumption : 2.0 W minimum / 3.6 W maximum
- Voltage : DC 24 V,(17~32 V, pulsating current enable)
- Current
- – Idel(Sensing) : 50 mA
- – Fire (Activating, Emergency) (Sensing) : 70 mA
- – Self test : 170 mA
|
